Switch Membrane for Siemens Handheld Unit 6FX2007-1AE14

Overview of 6FX2007-1AE14 Operator Keyboard
The handheld unit type B-MPI is suitable for manually operating machine tools, such as axis feed movements. All keys are freely assignable, and the keyboard can be optionally labeled.

Handheld unit of 6FX2007-1AE14 Switch Membrane
Handheld unit with handwheel, EMERGENCY STOP button, keyswitch, override, enabling buttons, display, free keys, connection via MPI bus and cable distributor.

Design of 6FX2007-1AE14 Membrane Keypad
The handheld unit features 2-channel emergency stop and enabling circuits.The enabling button is a 3-step enabling button. The 6FX2007-1AE14 Keyboard Membrane handheld unit is available for 3-wire or 4-wire enabling. The handheld unit type B-MPI is connected via a distributor box to the MPI line. The distributor box of 6FX2007-1AE14 Operator Keyboard is designed for installation in a control cabinet or in a separate enclosure. In the version with 4-wire connection of the enabling buttons, monitoring of the transverse short-circuit is possible in the enabling circuit. Due to the modified connector layout, these 6FX2007-1AE14 Terminal Keypad handheld units can be used only with the distributor box for this version. The holder of 6FX2007-1AE14 Operator Panel Keypad is manufactured from black polystyrene and can be fixed to a suitable base with 4 screws.
