DMC LST-215WB080A Touch Screen Panel Glass
group nameLST Series
-
Min Order1 piece
brand nameVICPAS
modelLST-215WB080A
payment methodWestern Union, MoneyGram, T/T, Paypal, PayPal, Credit Card
-
update timeFri, 05 Dec 2025 22:38:41 GMT
Paramtents
Size 21.5''
Tail Length & Position 80/ Left Side
External Dimension 500.3 x 293.2mm
Viewing Area Dimension 480.56 x 272.29mm
Active Area Dimension 476.56 x 268.29mm
Glass Thickness(Total) 1.8mm (2.1mm)
Warranty 365 days
Model LST-215WB080A
Packging & Delivery
Min Order1 piece
Briefing
Detailed
DMC LST-215WB080A Touch Screen Panel Glass Repair Replacement
The LST-215WB080A touch panel Electrical Characteristics use DC6V Maximum Voltage, and the connetion Top Electrode within 100mA, Between the Top and Bottom is 0.5mA. It have long Operating Life with 10,000,000 hits Input (finger).
The DMC LST-215WB080A screen size is 21.5'', 4 wire resistive touch screen panel glass. The touch screen External Dimension is 500.3 x 293.2mm, Viewing Area Dimension 480.56 x 272.29mm, Active Area Dimension 476.56 x 268.29mm, and Glass Thickness 1.8/ 2.1mm. Per DMC touch screen had been full test before shipping to customers.
VICPAS supply DMC LST-215WB080A touch screen panel for repair replacement, screen size 21.5''. All of them with VICPAS 365 days warranty and support Urgent Worldwide Shipping.
Specifications:
The table below describes the parameters of the DMC LST-215WB080A Touchscreen Panel Glass.
| Part Number : | LST-215WB080A |
| Manufacturer: | DMC LST |
| Screen diagonal | 21.5'' |
| Warranty: | 365 Days Warranty |
| Operating Life | 10,000,000 hits |
| Touchpoints: | 1 |
| Glass Strength: | 1.8mm (2.1mm) |
| Technology: | Analog resistive 4-wire |
| Active Area: | 476.56 x 268.29mm |
| Viewing Area Dimension | 480.56 x 272.29mm |
