group nameH-Series HMI
Min Order1 piece
brand nameVICPAS
modelH-T40m-POMR
payment methodWestern Union, T/T, PayPal, T/T ,Credit Card, Western Union
update timeFri, 01 Nov 2024 07:19:21 GMT
Brand Beijer
Warranty 180 days
Product Line H-series
Supply H-T40m-POMR Touchscreen
Part Number 300-54805
Size 3.5 INCH
Min Order1 piece
Beijer H-T40m-POMR 3.5'' graphic touch HMI kits include touchscreen and overlay
• 89 mm 3.5" display
• Gray monochrome
• Ethernet available
• 240 x 240 resolution
The H-series of operator panels offers valuable HMI functionality. The series include keypad and touch screen interfaces and are available in sizes from 3" to 10.4". Offering three levels of functionality, Standard, Plus enhanced and Network enhanced, the H-series enables you to select and pay for the level of HMI technology you need. All H-series operator panels are configured with the intuitive H-Designer software tool.
VICPAS supply Beijer Exter H-T40m-POMR touchscreen with 12 months warranty and support Urgent Worldwide Shipping.
The table below describes the parameters of the Beijer 300-54805 H-T40m-POMR HMI Parts.
Brand: | Beijer |
Touch type : | Resistive |
Input fuse: | Internal DC fuse |
Warranty: | 6-Months Warranty |
Product Line: | Beijer H-Series |
Display Type: | LCD |
Size: | 3.5 INCH |
Resolution: | 240x240 pixels |
Part number: | 300-54805 |
Display type: | Mono STN LCD |
Question: How to instiall H-T40m-POMR Terminal?
Answer:The basic H-Designer system requirements are as follows:
– PC - CPU 80586 or higher;
– Memory - 64 MB RAM or more;
– Hardware - 60 MB or more available hard drive space;
– Display - VGA or SVGA. Microsoft Windows with 256 colors or higher, and aresolution of 800×600 or higher.
Since all the programs in the H-Designer suite have been compressed, you need touncompress and install the software before using it.
Question: What is the Ladder Programming of Beijer H-Series operator panel?
Answer:TLadder logic is a method of drawing electrical logic schematics. It can also be used forprogramming controllers. A program in ladder logic, also called a ladder diagram, issimilar to a schematic for a set of relay circuits.
H-series operator terminals and H-Designer support ladder programming and functionsin a continuous, cyclical series of tasks called scan. When the operator terminalis running, your program should be in one of the following status: RUN, STOP,PAUSE, and ERROR, and you can control the status changing by using debug commandsand inserting instructions in your program.
Detailed information about using ladder programming as well as examples are availableby selecting Help/LadderPlus in H-Designer
Question: What is H-T40m-POMR mebrane keyboard HMI parts price?
Answer: Submit a fast quote, send VICPAS an email for best price.
