0.6" 15.24mm prestressed concrete strand EN10138 BS5896 ASTM A16

  • group namePrestressed Concrete Steel Strand

  • Min Order25 metric ton

  • brand nameChunpeng PC Wire and PC Strand

  • model15.24mm

  • payment methodL/C, D/A, D/P, T/T

  • update timeSat, 06 Mar 2021 11:03:40 GMT

Paramtents

  • Tensile strength 1460-1860Mpa

  • Diameter 6.5MM-21.8MM

  • Certification BV/ISO9001:2000/ SGS

  • Structure 1*3/1*7/1*19

  • Grade 270(1860Mpa)

  • Usage Construction Materilals

  • Package Roll Packing

  • Standard ASTM A416, BS5896, EN10138

  • Material 77B/82B

  • Product name 15.24mm prestressed concrete strand

Packging & Delivery

  • Size140cm x 140cm x 80cm

  • Weight25000.00kg / metric ton

  • Min Order25 metric ton

Briefing

CHUNPENG 0.6" 15.24mm prestressed concrete strand can be widely used in many applications.

Detailed

0.6" 15.24mm prestressed concrete strand EN10138 BS5896 ASTM A16
1. Item
0.6" 15.24mm prestressed concrete strand EN10138 BS5896  ASTM A16
2. Specification
1 x 7 wire, 1x2 wire,1x3 wire,1x19 wire
9.53mm, 12.7mm, 15.2mm, 15.7mm, 17.8mm, 21.8mm
3. Appliacation
Widely Used for any aqueduct, viaduct, bridge, tunnel and railway construction
4. Certificate
ISO9001:2000  SGS BV
5. Standard
ASTM A416, BS5896, JIS G3536, GB/T5223, EN10138,PREN6138
6. Output
500, 000 ton/year
7. Features
High tensile, low relaxation
8. Twist
Left and right-hand lay
9. Factory Test
Norminal diameter, breaking force, elongation at rupture, tensile strength, stress relaxation
property, relax value at 1000h
10. Packing
Standard Export Package (Wrapped by steel strips, waterproof cloth sheet, wooden pallet)
11. Original
Tianjin, China
12.  Payment
T/T, LC
13.  Delivery Time
in 10 days after we receive your deposit or LC
Packaging & Shipping
Inner Diameter: 760mm
Outside Diameter:1400mm Max
Coil’s width: 760mm
Coil’s Weight: 2500~3500 kg
We use vapors corrosion inhibiting technology on export anti-rust packing. Out side of the coil has 3 wraps.
 There are two wooden pallets on the bottom of the coil. The coil is eye to sky in the container.
