Continuous Color Coating Line (CCL) — Advanced prepainted steel coil production line with 3-coat 3-bake technology, vertical curing furnace, and ≥99.3% first-pass yield. Suitable for PVDF/HDP/SMP coated steel for architectural curtain walls and BIPV. Contact us for customized solutions and quotation.
Detailed
Overview
The Continuous Color Coating Line (CCL) is an advanced automated production system engineered for manufacturing high-performance pre-painted steel coils with superior appearance, corrosion resistance, weather durability, and functional surface properties. By integrating precision roll coating technology, multi-stage curing systems, intelligent process control, and online quality inspection, this production line delivers a complete solution for producing premium coated steel products including PVDF fluorocarbon coated steel, HDP high-durability polyester coated steel, and SMP silicone modified polyester coated steel.
Key Features
3-Coat 3-Bake High Film Thickness Technology
Enables premium product positioning with 20–40% higher selling price compared to conventional 2-coat 2-bake products.
Vertical Curing Furnace Design
Reduces floor space by approximately 40% compared to traditional horizontal furnaces, with uniform temperature distribution of ±3℃ for superior coating quality
Fully Automatic Laser Lap Welding
Advanced laser welding technology ensures stable weld quality during high-speed operation, minimizing production interruptions
High Production Efficiency
Coil change time ≤2 minutes, Overall Equipment Effectiveness (OEE) ≥90%, first-pass yield ≥99.3%
Cost-Effective Operation
Production cost reduction of 10–15% compared with traditional coating lines, with high paint utilization efficiency and lower energy consumption
Technical Specifications
| Parameter | Specification |
| Coil Change Time | ≤2 minutes |
| Overall Equipment Effectiveness (OEE) | ≥90% |
| First-Pass Yield | ≥99.3% |
Furnace Temperature Uniformity | ±3℃ |
Floor Space Reduction | ~40% vs. traditional horizontal furnace |
Production Cost Reduction | 10–15% vs. traditional coating lines |
Coating Types Supported | PVDF, HDP, SMP, functional architectural coatings |
Curing Process | 3-coat 3-bake (high film thickness) / 2-coat 2-bake |
Strip Joining Method | Fully automatic laser lap welding |
Entry Accumulator Type | Horizontal / Vertical available |
Applications
The Continuous Color Coating Line produces high-performance coated steel coils widely used in premium architectural curtain walls, BIPV (Building Integrated Photovoltaics) systems, airports, high-speed railway stations, landmark commercial buildings, and industrial facilities. The line's advanced coating material compatibility enables production of PVDF fluorocarbon coatings, HDP high durability polyester, SMP silicone modified polyester, and other functional architectural coatings, providing strong market competitiveness and product differentiation for steel manufacturers worldwide.
FAQ
What is the MOQ for a Continuous Color Coating Line?
MOQ is 1 set. Each production line is custom-engineered based on the customer's specific production requirements, target products, and site conditions.
Do you provide installation and commissioning services?
Yes. We offer full lifecycle services from engineering design and equipment manufacturing to installation, commissioning, and production optimization, ensuring smooth project delivery.
What coatings can this production line handle?
The line supports PVDF fluorocarbon coatings, HDP high-durability polyester, SMP silicone modified polyester, and other functional architectural coatings, with both 3-coat 3-bake and 2-coat 2-bake process options.
