For Standing Product Checkweigher Food Industry
group nameOnline automatic checkweigher
-
Min Order1 piece
brand nameSyndar
modelCW3023L05,CW3523L1,CW4023L2
payment methodT/T
-
update timeFri, 26 Feb 2021 17:00:01 GMT
Paramtents
checkweigher scales display graduation 0.02g;
Checkweigher machine checkweigher range 1-500g;
checkweigher accuracy ±0.2-0.5g;
Rejection device air blowing type, push rod type
Rejection device lever type, up and down flap optional;
Number of automatic checkweigher sections standard 2 sections, optional 3 sections;
Packging & Delivery
Min Order1 piece
Briefing
Using modern high-speed and high-precision digital filtering algorithms, suitable for various high-level product detection
Detailed
Using For standing product checkweigher, you can：
●Checkweigher machine has short weight determination time and high recognition accuracy.
●The checkweigher system uses modern high-speed and high-precision digital filtering algorithms.
●Checkweigher equipment communication option and host computer data sharing and control are ideal partners to realize Industry 4.0.
For standing product checkweigher advantage:
Dynamic weighing scale is SYNDAR's new online For standing product checkweigher，The in line checkweigher is suitable for various high-level product inspections and can accept product diversification.
●100% online inspection of each product to avoid penalties caused by poor quality.
●Checkweigher conveyor design can adjust parameters to front-end packaging equipment through weighing detection feedback.
●checkweigher definition: optimize and improve the production process, provide equipment operation efficiency and save materials
|
Product number
|
CW3023L05 |
CW3523L1 | CW4023L2 |
|
Display index
|
0.02g
|
0.05g | 0.1g |
|
Checkweighing range
|
1- 500g
|
2-1000g | 2- 2000g |
|
Checkweighing accuracy
|
± 0.2-0.5g
|
± 0.3-0.8g | ± 0.5-1g |
Weighing section size | L 300mm*W 230mm | L:350mm*W 230mm | L 400mm*W 230mm |
Applicable product size | L≤200mm，W≤230mm | L≤230mm，W≤230mm | L≤280mm，W≤230mm |
Weighing control system | Use SYNDAR weighing controller system V1.15 | ||
Belt speed | 5-90/minute | ||
Quantity | 20-50 kinds | ||
Rejection device | Air blowing type, push rod type, lever type, up and down flaps are optional; | ||
Number of checkweighing sections | Standard 2 sections, optional 3 sections; | ||
Standard technical parameters | Power supply: standard single-phase AC200~240V, 50/60Hz, 0.4KW, optional three-phase AC380V, 50/60Hz, 0.4KW Air source: dry 0.5~0.8MPa (5~8bar) Temperature: Operating temperature: 0℃~40℃, storage temperature: -20℃~60℃ Humidity: 10~90%RH, no condensation Protection level: IP30, IP54, IP65 optional Noise: ≤75db Machine weight: ≈60kg Working height: 750±50mm (confirm when ordering other heights) | ||
Material | checkweigher load cell: aluminum, stainless steel optional Roller: Aluminum Structure: stainless steel 304, belt checkweigher conveyor belt: white, food grade, polyurethane thermoplastic (TPU) | ||
Product size chart
Features of Glass X-ray inspection:
Maximum processing capacity of checkweigher software: 200 packages per minute (depending on the product and surrounding environment)
SYNDAR technology is the industry's leading checkweigher manufacturers, providing users with checkweigher food industry customization.
In line Checkweighers for Food can choose a variety of rejection methods (pneumatic lever or flat push rod) to reject overweight or underweight products
Applications
Checkweigher Solutions: food net weight inspection, food missing and less-packed inspection, whole box weight inspection.
Ultra-high-speed online automatic checkweigher detection in electronics, food, case checkweigher and other industries.
The industrial checkweigher is suitable for sorting by weight of stamping parts, die casting machines, spare parts, hardware, etc.
SYNDAR provides special Checkweigher Solutions for products, such as artificial fertilizers, and food for various farm animals.
