group nameWater & Ground Source Heat Pumps
Min Order5 piece
brand nameSuoher Inverter Heat Pumps Manufacturer
modelSHWW-6Y
payment methodL/C, T/T
update timeFri, 10 May 2024 23:06:19 GMT
Net size 560*470*675(mm)
Power supply 220V/1PH/50Hz
Net weight 66KG
Gross weight 74KG
Circulation pump Optional
Working mode Only heating
Size59cm x 50cm x 80cm
Weight74.00kg / piece
Min Order5 piece
1. Newdesign, new visible screws outside.
2. Heatingonly or heating/cooling.
3. Allcasing panels are easy to remove for maintenance.
4. Lownoise design, the compressor system is isolated from bottom plate with softrubber mounts.
5. Noisejacket for compressor.
6. Pinvalve is easily accessible for maintenance.
7. Withwater flow switch.
8. Withdrain pipes for heat exchangers.
9. Tube-in-shellheat exchangers for heating only units and plate heat exchangers forheating/cooling units.
10. Canwork with room thermostat, master controller, or smart grill signal.
11. Built-inEnergy Class A circulating pump as standard.
12. Weoffer
OEM/ODM service.
|
Model |
|
SHWW-4Y |
SHWW-6Y |
SHWW-10Y |
---|---|---|---|---|---|
Specification |
Heating capacity |
KW |
4 |
6.5 |
10.2 |
Heating power input |
KW |
0.9 |
1.46 |
2.3 |
|
Rated current |
A |
4.09 |
6.64 |
10.45 |
|
COP |
|
4.44 |
4.45 |
4.43 |
|
Max. water temp. |
℃ |
60 |
|||
Rated water temp. |
℃ |
55 |
|||
Water flow (using side) |
m3/h |
0.7 |
1.1 |
1.8 |
|
Water flow (ground source) |
|
0.9 |
1.3 |
2.0 |
|
Net weight |
kg |
58 |
66 |
72 |
|
Gross weight |
kg |
65 |
74 |
81 |
|
Noise |
db |
35 |
38 |
40 |
|
Connection pipe |
mm |
3/4" |
|||
Power supply |
|
220V/1PH/50Hz |
|||
Net dimension |
mm |
560*470*675 |
|||
Package dimension |
mm |
590*500*800 |
|||
Standard components |
Compressor |
Brand |
Highly rotary |
||
Quantiy |
1 |
||||
Condenser |
High efficiency tube in shell |
||||
Evaporator |
High efficiency tube in shell |
||||
4-way valve |
NO |
||||
Expansion valve |
Electronic expansion valve |
||||
Circulation pump |
Optional |
||||
Cabinet |
Galvanized white metal sheet |
||||
Controller |
LCD |
||||
High pressure switch |
3.0/2.4MPa |
||||
Low pressure switch |
0.02/0.15MPa |
||||
Water flow switch |
No |
||||
Pressure gauge |
Yes (high pressure gauge) |
||||
Working mode |
Only heating |
||||
Refrigerant |
R417A |
