TR-CK01 Full-Automatic Single-Wire Single-Insertion Terminal Crimping Machine
group namePlastic Shell Terminal Crimping Machine
-
Min Order1 piece
brand nameTuring
modelTR-CK01
payment methodWestern Union, MoneyGram, T/T
-
update timeFri, 05 Dec 2025 18:39:30 GMT
Paramtents
Power 220V 50/60Hz
Scope of processing AWG22#~AWG30# (Customizable)
Housing Pitch 1.0-3.96
Air Pressure 0.4-0.5MPa (Air Consumption Approx. 130~180nL/min)
Packging & Delivery
Size180cm x120cm x150cm
Min Order1 piece
Briefing
TR-CK01 Full-Automatic Single-Wire Single-Insertion Terminal Crimping Machine. Machine Functions: Multiple Detection Functions for Front and Rear Wire Cutting, Stripping, Crimping, Housing Insertion, etc.
Detailed
TR-CK01 Full-Automatic Single-Wire Single-Insertion Terminal Crimping Machine
Power Supply: 220V 50/60Hz
Dimension: 1400x1100x1650mm
Applicable Wire Gauge: AWG22#~AWG30# (Customizable)
Housing Pitch: 1.0-3.96
Cutting Length: 45-1000mm (Single/Double-End Housing Insertion, Crimping)
Cutting Precision: ±1mm (+Set Cutting Length*0.02)
Stripping Length: 0.1-15mm
Crimping Capacity: 2T
Control Method: PLC Motion Controller
Compressed Air: 0.4-0.5MPa (Air Consumption Approx. 130~180nL/min)
Pay-Off Machine: 18-Axis Pay-Off Rack (Electric Pay-Off Rack) Determined by Customer's Wire
Take-Up Machine: Automatic Conveyor Belt
Operating Temperature: -10℃~45℃ (Recommended 15℃~30℃)
Machine Functions: Multiple Detection Functions for Front and Rear Wire Cutting, Stripping, Crimping, Housing Insertion, etc.
Detection Capability: Detect Presence of Wire, Over-Tight Wire, Wire Knotting, Abnormal Crimping and Stripping, Air Pressure Drop, Presence of Terminal, Whether Terminal is Crimped, Presence of Housing, Whether Housing is Inserted in Place, Terminal Pressure Detection
Processing Speed: 300 pcs/h, if 6P pitch 2.5 with 4 wires simultaneously, it can reach 1200 pcs/h, multiple wires can be processed simultaneously according to wire diameter and housing width
Dongguan Turing Automation Technology Co., Ltd. was founded in 2020 and is located in Dongguan City, Guangdong Province. The company specializes in the production of: fully automatic terminal crimping machines, fully automatic automatic-automatic terminal crimping and tin-plating machines, ultra-quiet energy-saving terminal machines, silent copper strip machines, computerized wire cutting and stripping machines, coaxial wire stripping machines, fully automatic nylon cable tie machines, fully automatic winding and strapping machines, computerized heat shrinkable tube cutting machines, terminal machine molds, knife molds, and new energy automatic wire harness processing equipment, etc. It mainly serves wire harness processing enterprises in the automotive, motorcycle, electronics, household appliances, electrical and other industries.
We have rich industry experience and are a trustworthy supplier. Our holding/cooperative factories are equipped with advanced production equipment and skilled front-line employees. Fully aware that the company's development depends on product innovation and quality, we have established a quality management system that meets the requirements of international quality management systems. The company continuously launches original innovations based on market and customer needs, always maintaining the novelty and innovation of products. We think what customers think and prioritize what customers need. Providing customers with excellent services and meeting their needs is our eternal pursuit!
