Ronda positive displacement inner gear pump
- US $1,000.00
1 - 40,000 set
- US $50.00
40,001 - 999,999 set
group nameGEAR/ROTOR OIL PUMP
-
Min Order1 set
brand nameRONDA
modelBBG
payment methodT/T, L/C, D/P D/A, Credit Card, PayPal, Westem Union, Cash, Escrow
-
update timeMon, 17 Mar 2014 15:11:26 GMT
Paramtents
Theory Rotary Pump
Structure Gear Pump
Usage Oil
Power Electric
Standard or Nonstandard Standard
Fuel Electric
Pressure Low Pressure
Application Oil
Packging & Delivery
Min Order1 set
Briefing
2.apply to deliver oil
3.excellent self-absorption
4.equipped with relief valve
Detailed
Ronda positive displacement inner gear pump
1. Introduction:
1. Ronda positive displacement inner gear pump can be equipped with relief valve accoding to the need of clients.
2. The internal gear(outer rotor) is arc tooth outline and external gear(inner rotor) is short frame outer cycloid.
3.Apply to deliver the oil that viscosity is between 1-8°E, such as mineral oil and any liquid performed like oil.
4. Pump have many benefits like simple design, low noise, stable oil transportation, excellent self-absorption, high rotation speed, etc.
5. BBG performs a perfect power pump / lubricant pump / cooling pump in low-pressure hydraulic system and oil delivering system.
2. Product details:
| Working Principle: | Internal double gears |
| Main applications: | Oil |
| Driver: | Electric motor |
| Power Specs: | 380/415V 3phase; 220/240V 1phase; 50hz/60hz |
| Max.permissible fluid temperature: | 80°C(176°F) |
| Type of connection: | Thread |
| Installation position: | Horizontal |
| Casing/Inner parts material: | Cast iron /Cast iron |
| Shaft seal type: | Shaft seal ring |
| Free passage: | 00 mm |
| Maximum viscosity: | 300C.S.T |
| Maximum drive rating: | 1.5KW(2HP) |
| Maximum caliber: | 32mm(1 1/4inch) |
| Maximum discharge-side pressure: | 0.5Mpa(5bar) |
| Flow rate range: | 4-125L/min(1.1-33.0US.GPM |
3. Performance data:
| Model | Capacity | Pressure | Speed | Volumetric efficiency | Caliber | Motor power |
| (L/min) | (MPa) | (r/min) | (%) | (Inch) | (KW) | |
| BB/BBG-4 | 4 | 2.45 | 1500 | ≥80 | 3/8″ | 0.55 |
| BB/BBG-6 | 6 | 0.55 | ||||
| BB/BBG-10 | 10 | 0.55 | ||||
| BB/BBG-16 | 16 | 2.45 | 1500 | ≥90 | 3/4″ | 1.1 |
| BB/BBG-20 | 20 | 1.1 | ||||
| BB/BBG-25 | 25 | 1.5 | ||||
| BB/BBG-32 | 32 | 1.5 | ||||
| BB/BBG-40 | 40 | 2.45 | 1500 | ≥90 | 2.2 | |
| BB/BBG-50 | 50 | 3 | ||||
| BB/BBG-63 | 63 | 4 | ||||
| BB/BBG-80 | 80 | 2.45 | 1500 | ≥90 | 1″ | 5.5 |
| BB/BBG-100 | 100 | 5.5 | ||||
| BB/BBG-125 | 125 | 7.5 |
4. FAQ:
5. Pictures:
Excellent product made of carefully selected high-quality materials:
Meticulous details & fine appearance:
Safe packing with standard plywood case:
Many kinds of models can be chosen:
