Taoxing CCD Registratering Semi-Auto Thick Film Circuit Screen Printing Machine
group nameSemi-Automatic Flat Screen Printing Machine
-
Min Order1 set
brand nameTAOXING Screen Printing Machines Manufacturer
modelTX-CCD200A
payment methodT/T
-
update timeSat, 06 Dec 2025 03:29:40 GMT
Paramtents
Printing size 150mm*150mm
Packging & Delivery
Weight370kg / set
Min Order1 set
Briefing
CCD Semi-auto thick film circuit screen printing machine is suitable for thick film circuit.
Detailed
Introduction
Specifications
Vacuum bed: 230*230 mm
Max screen printing size: O.D 320*320mm
Substrate height：5 mm
Printing accuracy: 0.02 mm
Printing thickness deviation: 0.002mm
Printing capacity: 800pcs/hour
Air source: 0.4~0.6Mpa
Voltage: AC220V/50/60Hz
Power supply: 1kW
Weight: 370kg
Dimension: 123*740*134cm
Features
1. Squeegee carriage on Hard Chrome Plated solid steel shaft with linear bearing motion.
2. Adjustable screen frame holder
3. Variable printing stroke length
4. Single/Double stroke selection
5. Parallel screen frame movement(Convenient for spot UV varnish and low viscosity inks to avoid ink spillage all over the screen)
6. Peel off mechanism (To achieve fine reproduction of halftone dots and avoid smudging, bleeding and smearing)
7.Adjustable squeegee angle from 0 to 30º
8.Aluminium extruded squeegee holder & coater for even pressure
9.Bed movement for registration x, y, & Rotary ±10 mm
10.Emergency Rod / Stop for safety of operator
11.Castor wheels for easy mobility
12.Printing operation by foot switch or automatic cycle, with dwell timer 0-10 sec.
Detailed Images
Application
Why Choose TAOXING
Industrial Precision Screen Printing Equipment Manufacturing - TAOXING
TAOXING Specialty Screen Printing Machine is a leading manufacturer and supplier of specialty screen printing machines in China, with more than 10,000 devices installed and running in dozens of industries.
We have developed a number of patents and proprietary products, and continue to provide cost-effective and simple solutions for automating the flat and cylindrical screen printing production process in a variety of applications, including glass, electronics, bottles, ceramics, automobiles, printed advertising, etc.
TAOXING has been providing customers with professional screen printing machinery and its related equipment. With advanced technology and 20 years of experience, TAOXING ensures that every customer's needs are met.
Maintenance and Care Precautions
In order to ensure the stability and long-term performance of the equipment, regular maintenance is recommended, including cleaning the CCD camera, adjusting and replacing printing parts, checking and calibrating the registration system, etc.
Download document
FAQ
-How does a CCD visual system work?
Our CCD visual system uses advanced image processing technology to capture marks or specific patterns on printed materials through a camera, and then accurately locates each printed color layer to achieve high-precision registration.
- Why choose a CCD registered screen printer?
A CCD registered screen printer can significantly improve printing accuracy and production efficiency, especially in printing projects that require complex multi-color alignment. It can not only reduce scrap rates, but also save production time and labor costs.
What industries is this equipment suitable for?
