JVD16-125 Wholesale price 125a disconnect switch DIN rail isolator

  • group nameDIN rail isolator

  • Min Order1 piece

  • payment methodT/T, L/C, Credit Card, PayPal, Westem Union, Cash

  • update timeMon, 02 Mar 2020 13:48:30 GMT

Paramtents

  • Pole No 1,2,3, 4

  • Rated current(A) 63, 80, 100, 125

  • Rated voltage AC 230/400V

  • Rated frequency 50/60Hz

  • Rated short-circuit making capacity 6kA

  • Rated withstand current 2kA within 1sec

  • Electro-mechanical endurance 10000 cycles

  • Connection terminal Screw terminal

  • Installation On symmetrical din rail 35mmo

  • Terminal Connection Height H=19mm

Packging & Delivery

  • Min Order1 piece

Briefing

Hihg quality single pole 63amp isolation switch disconnector circuit breaker with CE certificate adaptable to padlock device.

Detailed

Technical Data

Pole No.: 1, 2, 3, 4

Rated current(A): 63, 80, 100, 125

Rated voltage: AC 230/400V

Rated frequency: 50/60Hz

Rated short-circuit making capacity: 6kA

Rated withstand current: 2kA within 1sec

Electro-mechanical endurance: 10000 cycles

Connection capacity: Rigid conductor 35mm ²

Connection terminal:Screw terminal

Pillar terminal with clamp

Installation:n symmetrical din rail 35mm

Panel mounting

Terminal Connection Height: H=19mm

 Construction and Feature









Capable of switch electric circuit with load

Adaptable to padlock device

Contact position indication

Capable of quickly releasing stored energy operation

Highlighted of high making and breaking capacity

High short-circuit current withstand capacity

Used as main switch for household and similar installation

Overall & Installation Dimensions
Wiring Diagram
