MESCO Stainless Steel Wire Mesh | SUS304/304L/316/316L/904L
group nameStainless Steel
-
Min Order1 square meter
brand nameMESCO Steel Wholesaler
modelMS-SSWM-2024
payment methodT/T
-
update timeSat, 29 Aug 2026 00:29:39 GMT
Paramtents
Material Grade SUS304 / SUS304L / SUS316 / SUS316L / SUS904L
Mesh Count 1 - 500
Wire Diameter 0.02 - 2.0 mm
Weave Type Plain Weave, Dutch Weave, Twill Weave
Standard GB/T 5330, ASTM E2016, ISO 9044
Packging & Delivery
Min Order1 square meter
Briefing
Detailed
DALIAN MESCO STEEL CO., LTD specializes in manufacturing stainless steel wire mesh across five material grades: SUS304, SUS304L, SUS316, SUS316L, and SUS904L. Our product portfolio covers three core lines: stainless steel sieve mesh, Dutch weave mesh, and plain weave printing mesh. All products comply with international standards GB/T 5330, ASTM E2016, and ISO 9044. From coarse to ultra-fine specifications covering all industrial filtration and screening needs. Wide wire diameter range for every application, from precision printing to heavy-duty screening. Custom manufacturing based on your technical drawings and material requirements. Complete deep processing services to deliver ready-to-install components. General-purpose austenitic stainless steel. Most widely used with balanced performance and competitive price. Ultra-low carbon design prevents intergranular corrosion after welding. Recommended for food and pharmaceutical use. 2-3% molybdenum improves resistance to chloride pitting. Ideal for marine and chemical corrosive environments. Ultra-low carbon plus molybdenum. Combines 304L weldability with 316 corrosion resistance. Super-austenitic stainless steel for sulfuric, phosphoric and other strong acid environments. Full specification list covering 100+ sizes available on request. Custom sizes manufactured to your requirements. Warp and weft wires interlace one-over-one. Flat surface, uniform mesh openings, high strength. The most versatile general-purpose wire mesh. Dense warp and sparse weft create a trapezoidal pore structure. High filtration precision with good flow, designed for precision filtration and solid-liquid separation. High-precision plain weave for screen printing. Ultra-flat surface, uniform thickness, stable ink transfer, exceptional print accuracy. Juice, syrup, edible oil, milk powder, starch. Liquid-solid separation and impurity removal. Compliant with food contact standards. Raw material screening, particle impurity removal, biological fermentation broth filtration. Smooth surface, easy to sanitize, meets GMP. Acid and alkali resistant. Resins, pigments, catalyst filtration and recovery. SUS904L handles strong acid media. Oilfield mud screening, lubricating oil filtration, catalytic cracking particle interception. Withstands high temperature and pressure. Precision screening and classification of ore, mineral powder, coal powder and powder metallurgy raw materials. Precision printing for glass, ceramics, electronic circuits and textiles. Plain weave printing mesh ensures uniform ink transfer. Spectral grade analysis Imported equipment Section-by-section testing Roll leveling and stress relief Moisture-proof packaging Leave your requirements and MESCO engineers will reply with a detailed solution within 24 hours.MESCO Stainless Steel Wire Mesh Solutions
Product Highlights
Full Mesh Range 1-500
Wire Dia. 0.02-2.0 mm
Custom Drawings & Samples
Cutting, Bending, Welding
Material Grades Comparison
SUS304
06Cr19Ni10 / 1.4301
SUS304L
022Cr19Ni10 / 1.4307
SUS316
06Cr17Ni12Mo2 / 1.4401
SUS316L
022Cr17Ni12Mo2 / 1.4404
SUS904L
015Cr21Ni26Mo5Cu2 / 1.4539
Technical Specifications - Sieve Mesh
Mesh Count Wire Dia. (mm) Aperture (mm) 500 x 500 0.025 0.0258 400 x 400 0.030 0.0335 325 x 325 0.035 0.0432 250 x 250 0.050 0.0516 200 x 200 0.058 0.0690 150 x 150 0.060 0.109 100 x 100 0.100 0.154 80 x 80 0.140 0.18 60 x 60 0.178 0.25 40 x 40 0.254 0.38 30 x 30 0.305 0.54 20 x 20 0.406 0.86 10 x 10 0.640 1.91 5 x 5 1.040 4.04 2 x 2 1.800 11.1 1 x 1 2.030 23.37 Technical Specifications - Dutch Weave
Mesh Count Warp Wire (mm) Weft Wire (mm) 12 x 64 0.58 0.40 24 x 110 0.35 0.25 40 x 200 0.18 0.14 60 x 300 0.14 0.09 80 x 700 0.10 0.08 120 x 1100 0.08 0.05 200 x 1400 0.07 0.04 325 x 2300 0.035 0.025 400 x 2800 0.030 0.02 500 x 3500 0.025 0.018 635 x 4000 0.020 0.014 Technical Specifications - Printing Mesh
Mesh Count Wire Dia. (mm) Aperture (mm) 420 0.022 0.0385 400 0.022 0.0415 350 0.022 0.0506 325 0.030 0.0482 280 0.035 0.0557 250 0.030 0.0716 200 0.050 0.0770 180 0.050 0.0911 150 0.060 0.1093 120 0.080 0.1317 80 0.050 0.2675 Chemical Composition (%)
Element SUS304 SUS304L SUS316 SUS316L SUS904L Carbon C ≤ 0.08 ≤ 0.03 ≤ 0.08 ≤ 0.03 ≤ 0.02 Chromium Cr 18.0-20.0 18.0-20.0 16.0-18.0 16.0-18.0 19.0-23.0 Nickel Ni 8.0-10.5 8.0-12.0 10.0-14.0 10.0-14.0 23.0-28.0 Molybdenum Mo - - 2.0-3.0 2.0-3.0 4.0-5.0 Copper Cu - - - - 1.0-2.0 Iron Fe Balance Balance Balance Balance Balance Three Product Lines
Stainless Steel Sieve Mesh
Plain Weave Sieve Mesh
Stainless Steel Dutch Weave
Dutch Weave Mesh
Plain Weave Printing Mesh
Screen Printing Mesh
Cross-Industry Applications
Food & Beverage
Pharmaceutical
Chemical & Coatings
Oil & Energy
Mining & Metallurgy
Screen Printing
Full-Process Quality Control
Raw Material
Precision Weaving
Mesh Inspection
Flattening
Packaging
International Standards & Certifications
