Traditional Chinese Medicine Sterilizer Steam Autoclave for Herbal powder and material
group nameHerbal Steam Autoclave
-
Min Order1 piece
brand nameAIKSMED Steam Autoclave Sterilizer Manufacturer
modelMYD-0.2,MYD-0.25, MYD-0.28, MYD-0.36, MYD-0.4, MYD-0.5, MYD-0.6, MYD-0.8, MYD-1.0A, MYD-1.0B, MYD-1.2, MYD-1.5, MYD-2.0A, MYD-2.0B, MYD-2.5, MYD-3.0, MYD-4.0, MYD-5.0
payment methodL/C, D/A, D/P, Western Union, MoneyGram, T/T, Paypal
-
update timeSat, 11 Apr 2026 16:38:03 GMT
Paramtents
Loading Capacity 200L/250L/280L/360L/430L/540L/650L/820L...5000L
Customized Available
Application Herbal materials and powder
Door Pass-through Double Hinged Doors/Sliding Doors
Packging & Delivery
Min Order1 piece
Briefing
After repeated process verification, AIKSMED found steam sterilization is the most suitable method for herbal medicines, and hereby launches Herbal Medicine Steam Sterilizer. The structure is horizontal rectangular, internal and external steam heating. It is designed with a unique moisture-proof device, powder agglomeration in traditional steam sterilization can be avoided.
Detailed
Herbal Medicine Steam Sterilizer
Conventional disinfection treatment on herbal medicines are cobalt 60, ethylene oxide, alcohol, microwave, ozone and etc. However, it is difficult to ensure drug properties due to chemical residues, or the cost is expensive.
Design pressure | -0.1/0.3Mpa |
Working pressure | 0.25Mpa |
Design temperature | 144℃ |
Working temperature | 137℃ |
Max. vacuum | -0.096Mpa |
Thermal uniform | ≤±1℃ |
Steam pressure | 0.3-0.5Mpa |
Water pressure | 0.15-0.35Mpa |
Compressed air pressure | 0.5-0.7Mpa |
Model | Volume
(L) | Chamber Size
(L×W×Hmm) | Overall Size
(L×W×Hmm) | Power
(KW) | N/W
(KG) |
MYD-0.2 | 200 | 780×500×500 | 1020×1200×1740 | 1.2 | 700 |
MYD-0.25 | 250 | 1000×500×500 | 1240×1200×1740 | 1.2 | 750 |
MYD-0.28 | 280 | 780×600×600 | 1040×1270×1740 | 1.6 | 780 |
MYD-0.36 | 360 | 1000×600×600 | 1260×1270×1740 | 1.6 | 880 |
MYD-0.4 | 400 | 1200×600×600 | 1460×1270×1740 | 1.6 | 950 |
MYD-0.5 | 500 | 1500×600×600 | 1760×1270×1740 | 1.6 | 1000 |
MYD-0.6 | 600 | 1180×610×910 | 1440×1280×1940 | 2.4 | 1200 |
MYD-0.8 | 800 | 1480×610×910 | 1740×1280×1940 | 2.4 | 1400 |
MYD-1.0A | 1000 | 1800×610×910 | 2060×1280×1940 | 2.4 | 1600 |
MYD-1.0B | 1000 | 1250×680×1180 | 1580×1460×2040 | 2.4 | 1600 |
MYD-1.2 | 1200 | 1500×680×1180 | 1780×1460×2040 | 3.2 | 1700 |
MYD-1.5 | 1500 | 1900×680×1180 | 2180×1460×2040 | 4.2 | 1850 |
MYD-2.0A | 2000 | 2600×680×1180 | 2900×1460×2040 | 4.2 | 2400 |
MYD-2.0B | 2000 | 1700×1000×1200 | 2000×2000×2040 | 4.2 | 2400 |
MYD-2.5 | 2500 | 2100×1000×1200 | 2400×2000×2040 | 4.2 | 2700 |
MYD-3.0 | 3000 | 2520×1000×1200 | 2820×2000×2040 | 5.7 | 3200 |
MYD-4.0 | 4000 | 3340×1000×1200 | 3640×2000×2040 | 5.7 | 3700 |
MYD-5.0 | 5000 | 4200×1000×1200 | 4500×2000×2040 | 7.7 | 4200 |
