Internal Combustion Hydraulic High-Lift Track Lifting Machine
group nameTrack Stabilization & Alignment Systems
-
Min Order1 piece
brand nameRailway Maintenance Equipment & Solutions
modelYQJ-250(G)
payment methodT/T, L/C, D/P D/A
-
update timeTue, 26 May 2026 06:22:33 GMT
Packging & Delivery
Min Order1 piece
Briefing
A specialized Track Lifting Machine for track lifting and lining operations on railway lines.
Detailed
Overview
The YQJ-250 On-track Hydraulic Rail Lifter is suitable for track lifting operations on various rail types. This machine is equipped with a safe and reliable insulation device that meets track circuit requirements, and comes with travel and off-tracking devices. It features safe and reliable operation, flexible control, and easy maintenance.
Technical Parameters of the YQJ-250 On-track Hydraulic Rail Lifter:
⚪ Power Source: HONDA GX390 Gasoline Engine
⚪ Power: 9.5 kW
⚪ Fuel Consumption Rate: 310 g/kW.h
⚪ Lubricating Oil Capacity: 1.12 L
⚪ Maximum Lifting Force: 125 × 2 kN
⚪ Maximum Single-Stroke Lifting Height: 500 mm
⚪ Working Pressure: 15-16 MPa
⚪ Working Flow Rate: 23 L/min
⚪ Manual Pump Flow Rate: 75 mL per reciprocating cycle
⚪ Overall Dimensions (L × W × H): 1650 mm × 850 mm × 1100 mm
⚪ Unit Weight (including hydraulic oil): 370 kg
Operating Instructions for the Hydraulic Rail Lifter/Line Adjuster
⚪ For Lifting: Place the machine beneath the rail base, ensuring the rail base contacts the lifting wheel and the rail base side contacts the limit stop. (For Line Adjustment: Place the machine beneath the rail base, ensuring the rail side contacts the lining stop.) Then, lower the carrying beam and close the oil return valve.
⚪ Operate the pumping lever to actuate the oil pressure rocker arm. Stop the lifting/lining operation when the piston rod extends to the visible safety warning line.
⚪ Once the desired lifting/lining height is achieved, stop pumping. Press the oil return handle to retract the piston into the cylinder, resetting the working cylinder. The lifting/lining task is now complete.
