Automatic Yogurt Cup Filling Sealing Machine - Pudding & Ice Cream Cup Filler
group namePaste Filling Machine
-
Min Order1 set
brand nameTOP Y Machinery
modelTOPY-FM
payment methodT/T
-
update timeTue, 18 Aug 2026 18:01:22 GMT
Paramtents
packaging type Cans, Bottles, Bags, Jar, Other
key selling points Energy Saving
core components Motor, PLC, Engine
machinery test report Provided
video outgoing-inspection Provided
Product name Paste filling machine
Filling product Peanut butter, spice paste etc
Packging & Delivery
Size100cm x120cm x150cm
Weight450kg / set
Min Order1 set
Briefing
Detailed
Automatic Yogurt Cup Filling Sealing Machine for Pudding & Ice Cream Cups
Fill and heat-seal yogurt, pudding and ice cream cups in one automatic line — precise piston filling, food-grade stainless build, plug-and-play dairy cup production.
- Fill + Seal in One Line
- 8 Cup Filling Stations
- PLC Touch-Screen Control
- Food-Grade 304 Stainless
A Yogurt Cup Filling Machine That Keeps Dairy Flowing
Yogurt, pudding and ice cream cups are thick, creamy and temperature-sensitive. Ordinary fillers splash, under-fill and struggle with cup changeovers. TOPY-FM uses a positive-displacement piston system with anti-drip nozzles — engineered for high-viscosity dairy cup filling and sealing.
(weight-based consistency)
(expandable)
(adjustable)
(CIP-friendly)
Key Components of a Reliable Cup Filling Sealing Machine
Every module of this automatic yogurt cup filling machine is selected for clean, hygienic dairy production.
Cup Filling Heads
Multiple filling heads meter exact cup volume per cycle; head count matches your dairy output.
Anti-Drip Nozzles
Clean-cut nozzle mouths deliver splash-free filling and prevent dripping between cups.
Hygienic 304 Build
Stainless-steel structure, tidy filling session and easy-to-clean surfaces for food safety.
Brand Motor + PLC
Famous-brand motor and PLC touch-screen control deliver stable, repeatable cup filling.
Why Dairy Factories Choose This Cup Filler
- Gentle with Thick DairyPiston metering keeps yogurt and pudding flowing without shear damage or curdling.
- Weight-Consistent Accuracy±0.5% repeatability keeps every cup within spec — less giveaway, fewer complaints.
- Splash-Free, Less WastePrecision nozzles eliminate drips and splashes between cups, keeping the line clean.
- Fast Cup ChangeoverQuick-adjust fill range and tool-free cleaning support multi-SKU dairy production.
More Than a Cup Filler — a Dairy Growth Engine
- Higher Output, Fewer HandsAutomated cup filling and sealing replaces manual spoon-filling, cutting labor cost.
- Less Product Giveaway±0.5% accuracy on dairy products means measurable savings in every shift.
- OEM / ODM CustomizationBrand your machine with your logo and colors; private-label supply supported.
- One-Stop Line ExtensionAdd sealing and labeling machines to build a complete dairy filling line.
Application: Yogurt, Pudding & Ice Cream Cup Filling
TOPY-FM is built around yogurt cup filling and sealing — the applications below extend the same machine to other dairy and semi-solid cup products.
HoneyViscous sweetener
Fruit JuiceBeverage
MilkDairy beverageCup Filling Machine for Multiple Cup Formats
Compatible with standard dairy cup formats and sealing film types.
Standard CupsRound yogurt cups
Dessert CupsPudding & cream cups
Ice Cream CupsFrozen dessert cupsTOPY-FM Cup Filling Sealing Machine Specifications
| Model | TOPY-FM |
|---|---|
| Filling Type | Piston (positive displacement) — dairy cup filling |
| Filling Stations | 8 stations (configurable) |
| Fill Range | 100 – 1000 ml per cup (adjustable) |
| Capacity | Up to 2000 cups/hour* |
| Filling Accuracy | ±0.5% |
| Sealing System | Heat sealing integrated (film or foil) |
| Power | 1.1 kW (filler) · AC220V 50/60Hz |
| Machine Dimension | 2000(L) × 1100(W) × 2200(H) mm* |
| Air Source | 0.6 – 0.8 MPa clean, stable air supply |
| Contact Parts | Food-grade 304 stainless steel |
| Control System | PLC + touch screen |
| Optional Upgrades | Capping machine · Sealing machine · Labeling machine |
Build a Complete Dairy Cup Filling Production Line
TOPY-FM integrates seamlessly with upstream and downstream machines for end-to-end cup automation.
Cup Depalletizing
Cup Filling(TOPY-FM)
Sealing
Labeling
Cup CollectingComplete Your Line with Add-On Machines
Capping MachineScrew-cap tightening for bottles & jars
Sealing MachineInduction / heat sealing for leak-proof packs
Labeling MachineRound & flat-surface labeling for bottles & jars
15+ Years of Packaging & Filling Expertise
- Professional manufacturer focused on packaging & filling machines since 2011
- Machinery test report provided before shipment
- Video outgoing inspection available for every order
- OEM / ODM private-label support for distributors & brands
- Global export experience — trusted by food brands worldwide
Frequently Asked Questions
Can it fill yogurt with fruit chunks?
Yes. The piston metering system handles semi-solid dairy with small particles. Confirm chunk size during inquiry so we can match the nozzle and piston configuration.
What cup sizes are supported?
Fill range is adjustable from 100 to 1000 ml. Share your cup diameter during inquiry and we will confirm tooling compatibility.
How does the heat sealing work?
Sealing is integrated with the filling line, applying film or foil lids with adjustable temperature and time for a leak-proof seal.
How long does cleaning and changeover take?
Contact parts are stainless steel with simplified disassembly, supporting fast cleaning between dairy products and cup sizes.
Can I add capping and labeling later?
Absolutely. TOPY-FM is line-ready: add sealing, labeling machines anytime for a full dairy line.
Ready to Automate Your Yogurt Cup Filling?
Tell us your cup format, product and target output in the inquiry form below — our engineers will recommend the right TOPY-FM configuration and respond with a tailored quotation. You can also download the catalog to explore the full filling machine range.
