Aluminum Picture Window Fixed Glass Window Manufacturer
group namePicture Window
-
Min Order1 piece
brand nameFOWALL Curtain Wall System Supplier
-
update timeMon, 13 Jul 2026 18:28:42 GMT
Packging & Delivery
Min Order1 piece
Briefing
High-performance aluminum picture window designed for maximum daylight and unobstructed views, offering superior thermal insulation, airtightness, and modern architectural aesthetics.
Detailed
Picture Window – Product Overview
The aluminum picture window is a fixed, non-operable window system designed to maximize natural light and provide panoramic views. Without opening mechanisms, it offers excellent airtightness and thermal performance. Built with high-strength aluminum frames and advanced glazing systems, it is ideal for modern residential and commercial architecture.
Why Choose Our Aluminum Picture Window
● Maximum Natural Light
Large glass panels allow abundant daylight, enhancing indoor brightness and comfort.
● Panoramic View
Fixed design provides uninterrupted outdoor views, ideal for modern architectural aesthetics.
● Superior Energy Efficiency
No opening gaps ensure excellent insulation and reduced energy loss.
● High Structural Strength
Engineered for large panel sizes with strong aluminum profiles.
● Low Maintenance
No moving parts, ensuring long-term durability and minimal maintenance.
Technical Performance
| Item | Performance | |
| Wind Load Resistance | 3000–7000 Pa (ASTM E330) | |
| Water Tightness | ≥ 400–700 Pa (ASTM E331) | |
| Air Infiltration | ≤ 0.01–0.05 cfm/ft² (ASTM E283) | |
Thermal Performance | 0.8–1.8 W/m²·K | |
| Acoustic Insulation | 35–50 dB | |
Glass Thickness | Up to 6mm + 12A + 6mm (or customized) | |
Corrosion Resistance | 2000-hour Salt Spray Test (ASTM B117) | |
Applications – Commercial Projects
· Office Buildings
· Shopping Malls
· Hotels
· Commercial Complexes
· Public Infrastructure
This aluminum glass curtain wall facade is widely used in modern urban architecture requiring both performance and aesthetics.
FAQ –Picture Window System
Q1: Can the picture window support large panel sizes for our project design?
Yes, our picture window system is engineered for large glass panels with reinforced aluminum profiles. We can customize dimensions based on structural calculations to ensure safety and stability for large openings.
Q2: What thermal performance can you achieve for energy-efficient buildings?
Our picture windows can achieve U-values as low as 0.8 W/m²·K when combined with double or triple glazing and Low-E glass, meeting energy efficiency standards for residential and commercial projects.
Q3: How do you ensure airtightness and water tightness?
As a fixed, non-opening system, picture windows offer superior airtightness. We use high-performance sealing systems and precision fabrication to achieve excellent air and water tightness performance.
Q4: Can you provide customized solutions based on facade drawings?
Yes, we fully support customization based on architectural and facade drawings. Our team can provide shop drawings, structural suggestions, and optimized solutions for your project.
Q5: Do you provide project support?
Yes, we provide:
· Shop drawings
· Engineering solutions
· Installation guidance
· OEM/ODM services
