Visible curtain wall Aluminum Glass Facade system Manufacturer Fowall
group nameVisible Curtain Wall
-
Min Order1 piece
brand nameFOWALL Curtain Wall System Supplier
-
update timeSat, 18 Jul 2026 16:52:48 GMT
Paramtents
Frame Type Visible Frame Curtain Wall
Material Aluminum Alloy + Tempered Glass
Glass Type Double Glazing / Laminated Glass / Low-E Glass / Triple Glazing
System Type Stick System / Semi-unitized Curtain Wall
Surface Treatment Powder Coating / PVDF Coating / Anodized
Application Commercial Buildings / Office Towers / Shopping Malls / Hotels
Packging & Delivery
Min Order1 piece
Briefing
High-performance visible frame curtain wall system designed for commercial buildings, offering structural stability, cost efficiency, and modern architectural facade aesthetics.
Detailed
Visible Curtain Wall – Product Overview
The visible frame curtain wall system is one of the most widely used architectural facade solutions for commercial buildings. Featuring exposed aluminum framing and high-performance glazing, it provides reliable structural support, efficient installation, and a clean modern appearance. Suitable for various building types, the system combines durability, flexibility, and cost-effective facade construction.
Why Choose Our Aluminum Glass Visible Curtain Wall
● Strong Structural Stability
Exposed aluminum framing ensures reliable mechanical fixing and long-term safety.
● Cost-effective Facade Solution
Compared with unitized systems, visible curtain walls reduce manufacturing and installation costs.
● Flexible Architectural Design
Supports various glass configurations, profile finishes, and facade layouts.
● Easy Installation & Maintenance
Stick-built structure allows convenient on-site assembly and future maintenance.
● Energy-efficient Performance
Compatible with Low-E insulated glass and thermal break systems.
Engineered with mechanically fixed aluminum framing, the system delivers excellent performance under wind load and seismic conditions.
✔ Cost-Effective Commercial Solution
Lower manufacturing and installation costs compared to unitized curtain wall systems, ideal for budget-controlled projects.
✔ Flexible Architectural Design
Supports various:
· Glass types (Low-E, laminated, double glazing)
· Surface finishes (PVDF, anodized, powder coating)
· Colors and facade styles
✔ Easy Installation & Maintenance
· On-site assembly allows flexible adjustments
· Convenient for long-term repair and replacement
· Suitable for international construction projects
✔ Proven Performance & Compliance
· Meets ASTM and AAMA standards
· Excellent water tightness and air sealing
· Long-term corrosion resistance for coastal environments
Technical Performance
| Item | Performance | |
| Wind Load Resistance | 3000–7000 Pa | |
| Water Tightness | ≥ 300–600 Pa | |
| Air Infiltration | ≤ 0.06–0.3 cfm/ft² | |
Thermal Performance | 1.2–2.5 W/m²·K | |
| Acoustic Insulation | 35–50 dB | |
Seismic Performance | ±20–25 mm Inter-story drift | |
Corrosion Resistance | 2000h Salt Spray Test | |
Applications – Commercial Projects
· Office Buildings
· Shopping Malls
· Hotels
· Commercial Complexes
· Public Infrastructure
This aluminum glass curtain wall facade is widely used in modern urban architecture requiring both performance and aesthetics.
FAQ – Visible Frame Curtain Wall System
Q1: What is the difference between visible frame and unitized curtain wall?
Visible frame systems are installed on-site and are more cost-effective, while unitized systems are pre-assembled in factories.
Q2: Is this system suitable for high-rise buildings?
Yes, it is designed to meet high wind load and seismic performance standards.
Q3: Can the glass and color be customized?
Yes, we offer full customization for glass types, coatings, and aluminum finishes.
Q4: What standards does the system comply with?
It complies with ASTM, AAMA, and international facade standards.
Q5: Do you provide project support?
Yes, we provide:
· Shop drawings
· Engineering solutions
· Installation guidance
· OEM/ODM services
