19.2‑inch color active‑matrix TFT‑LCD module

This 19.2-inch color active-matrix TFT-LCD module is designed for professional display applications that require high image quality, stable performance, and flexible system integration. Utilizing advanced amorphous silicon TFT technology, the module delivers excellent display performance with reliable operation for industrial, automotive, transportation, and other embedded applications.

The module features a Full HD resolution of 1920 × 359 pixels, providing a wide panoramic display area with sharp details and clear image reproduction. Its LVDS interface supports 2 pixel/clock transmission, enabling high-speed signal communication, improved data stability, and reduced electromagnetic interference. With a 6-bit + Hi-FRC color depth, the display is capable of reproducing up to 16.7 million colors, ensuring smooth color transitions, accurate image rendering, and enhanced visual performance.

The display adopts an edge-type LED backlight structure with one light bar design, achieving a high luminance level of 500 cd/m² for improved readability in various lighting environments. Combined with a high contrast ratio, the module provides deeper blacks, brighter whites, and better overall image clarity. The wide viewing angle of ≥85° in all directions allows users to experience consistent brightness and color performance from different viewing positions. The low-reflection surface design helps minimize glare and improve visibility, especially in environments with strong ambient lighting.

Supporting both landscape and portrait orientations, this TFT-LCD module offers flexible installation options for different product designs and application scenarios. The DE-only mode simplifies interface control and enhances compatibility with various electronic systems. Integrated gamma correction technology further optimizes grayscale performance, brightness uniformity, and overall image quality.

Designed with environmental compliance and long-term reliability in mind, the module is RoHS compliant and halogen-free, meeting global requirements for environmentally friendly products. It is engineered to operate under challenging temperature conditions, with a wide operating temperature range from –20°C to +70°C and a storage temperature range from –30°C to +80°C.

With its combination of high brightness, excellent color performance, wide viewing angle, low reflection, flexible mounting orientation, and robust environmental durability, this 19.2-inch TFT-LCD module is an ideal choice for industrial control systems, smart equipment, vehicle displays, medical devices, and other applications requiring dependable and high-performance display solutions.
