1500V Main Cable For BESS HDPE
group nameAustralia Standard
-
Min Order1 piece
brand nameSUNKEAN Solar Manufacturer
payment methodT/T, L/C
-
update timeSat, 28 Feb 2026 23:40:52 GMT
Paramtents
Conductor Aluminum
Insulation X-90 XLPE
Jacket HDPE
Rated voltage 1500V DC
Rated temperature -40°C ~ +90°C
Packging & Delivery
Min Order1 piece
Briefing
Cables for use in BESS projects, manufactured complying with Australian and international standards.
Detailed
1500V Main cable Introduction
1500V Main Cable For BESS HDPE
Cables for use in BESS projects, manufactured complying with Australian and international standards such as AS/NZS 5000.1 AS/NZS 1429.1 AS/NZS 1125 AS/NZS 3808 AS/NZS 3033.
1500V Main Cable Technical Data
|
Conductor
|
Aluminum
|
|
|
Insulation
|
X-90 XLPE |
|
Nylon layer | Nylon | |
Jacket | HDPE | |
|
Rated temperature
|
-40°C ~ +90°C
|
|
|
Rated voltage
|
U=1500V DC,
U0/U=1000V/1000V AC |
|
Test voltage | 6.5kVAC / 5min | |
Maximum Short-Circuit Temperature | 250°C/5s | |
Max. DC Voltage | UM=1800V DC | |
According to | AS/NZS 5000.1 AS/NZS 1429.1 AS/NZS 1125 AS/NZS 3808 AS/NZS 3033 | |
1500V Main Cable Product description
Conductor Area | Insulation Thichness | Jacket Thickness | Cable OD | Approx. Mass of Cable (kg/km) | Conductor Resistance Max (Ώ/km,20°C) |
16 | 0.7 | 1.4 | 11.4 | 89 | 1.91 |
25 | 0.9 | 1.4 | 12.8 | 127 | 1.2 |
35 | 0.9 | 1.4 | 13.8 | 160 | 0.868 |
50 | 1.0 | 1.4 | 15.1 | 204 | 0.641 |
70 | 1.1 | 1.4 | 17.0 | 277 | 0.443 |
95 | 1.1 | 1.5 | 18.8 | 364 | 0.320 |
120 | 1.2 | 1.5 | 20.5 | 448 | 0.253 |
150 | 1.4 | 1.6 | 22.6 | 551 | 0.206 |
185 | 1.6 | 1.6 | 24.6 | 678 | 0.164 |
240 | 1.7 | 1.7 | 27.4 | 870 | 0.125 |
300 | 1.8 | 1.8 | 30.0 | 1070 | 0.100 |
400 | 2.0 | 1.9 | 33.4 | 1357 | 0.0778 |
