Bathtub Water Pump TDA Series Wholesale | High Performance Whirlpool Bathtub Water Pumps of Various Specifications | Available at Wholesale
group nameWater Pumps
-
Min Order50 piece
brand nameHydrorelax Bathroom industry manufacturer
modelTDA35, TDA50, TDA75, TDA100, TDA120, TDA150, TDA200
payment methodT/T, L/C, D/P D/A, Credit Card, PayPal, Westem Union
-
update timeSun, 07 Dec 2025 01:39:54 GMT
Paramtents
Thermal protector: with Thermal protecto (single phase motor)
Insulation rating: F
Protection class: IP55
Medium temperature: 5~50℃
Ambient temperature: ≤50℃
Maximum working pressure: 0.3MPa
Certification: CE ; TUV ; SAA ; UL
Packging & Delivery
Min Order50 piece
Briefing
0.25KW/0.35HP~1.5KW/2.0HP
150~450 QMAX(L/MIN)
150~450 QMAX(L/MIN)
Detailed
Bathtub Water Pump Parameter
Bathtub Water Pump Performance Curve
Bathtub Water Pump Dimension
Bathtub Water Pump Exploded View
NO. | NAME | |||
1 | Tie-in Nut | |||
2 | Tie | |||
3 | O-Ring | |||
4 | Cross Raised Head Screw Assembling | |||
5 | Pump Cover | |||
6 | O-Ring | |||
7 | Impeller | |||
8 | Mechanical seal | |||
9 | Pump Casing | |||
10 | Motor | |||
Bathtub Water Pump Applications
