EH 299 Series - VEP-P ISO 16028 Threaded Flat Face Quick Coupling (Steel)
group nameFlat Face ISO 16028 Quick Couplers
-
Min Order1 piece
brand nameEH
-
update timeFri, 05 Dec 2025 20:24:13 GMT
Paramtents
Interchange STUCCHI VEP-P SERIES
Interchange PARKER FET SERIES
Interchange FASTER FHV SERIES
Interchange VOSWINKEL FT SERIES
Interchange DIXON VEP SERIES
Interchange DNP PST4 SERIES
Packging & Delivery
Min Order1 piece
Briefing
This EH series is interchangeable with STUCCHI VEP-P SERIES, PARKER FET SERIES, FASTER FHV SERIES, VOSWINKEL FT SERIES, DIXON VEP SERIES, and DNP PST4 SERIES. Steel Product. Engineered for demanding hydraulic systems, the 299 Series provides reliable performance in applications subject to extreme pressure impulses and residual line pressures. The innovative thread-to-connect design significantly reduces wear and prevents brinelling, while the internal valve technology enables safe connection and disconnection even under high residual pressure conditions. This series is used in a high wind application environment, and the safety pin lock will ensure the couplers are physically stable enough to perform properly.
Detailed
299 Series
Threaded Flat Face Coupling (Steel)
ISO-16028 Standard, Connect Under Pressure
This EH series is interchangeable with STUCCHI VEP-P SERIES, PARKER FET SERIES, FASTER FHV SERIES, VOSWINKEL FT SERIES, DIXON VEP SERIES, and DNP PST4 SERIES. Engineered for demanding hydraulic systems, the 299 Series provides reliable performance in applications subject to extreme pressure impulses and residual line pressures. The innovative thread-to-connect design significantly reduces wear and prevents brinelling, while the internal valve technology enables safe connection and disconnection even under high residual pressure conditions. This series is used in a high-wind application environment, and the safety pin lock will ensure the couplers are physically stable enough to perform properly.
Female
| Other Threads/Fitting Ends Are Available Upon Request | ||||||
| Art. No. | Body Size (inch) | E(mm) | Hs(mm) | Hq(mm) | Ls(mm) | T |
| HFSFC29938 -3/8"NPT | 3/8'' | 41.8 | S30 | S38 | 70 | 3/8"NPT |
| HFSFC29938 -3/8"G | 3/8'' | 41.8 | S30 | S38 | 70 | 3/8"BSPP |
HFSFC29938 -1/2"NPT | 3/8'' | 41.8 | S30 | S38 | 71.5 | 1/2"NPT |
HFSFC29938 -1/2"G | 3/8'' | 41.8 | S30 | S38 | 71.5 | 1/2"BSPP |
HFSFC29912 -1/2"NPT | 1/2'' | 49.8 | S36 | S46 | 78 | 1/2"NPT |
HFSFC29912 -1/2"G | 1/2'' | 49.8 | S36 | S46 | 78 | 1/2"BSPP |
HFSFC29912 -1-1/16" UN | 1/2'' | 49.8 | S36 | S46 | 85 | 1-1/16"UN-12 |
HFSFC29958 -3/4"NPT | 5/8'' | 53.8 | S41 | S50 | 85 | 5/8"NPT |
HFSFC29958 -1-1/16" UN | 5/8'' | 53.8 | S41 | S50 | 85 | 1-1/16"UN-12 |
HFSFC29934 -1"NPT | 3/4'' | 58.8 | S46 | S55 | 99 | 1"NPT |
HFSFC29934-1"G | 3/4'' | 58.8 | S46 | S55 | 99 | 1"BSPP |
HFSFC29934 -1-1/16" UN | 3/4'' | 58.8 | S46 | S55 | 99 | 1-1/16"UN-12 |
HFSFC29934 -1-5/16" UN | 3/4'' | 58.8 | S46 | S55 | 99 | 1-5/16"UN-12 |
HFSFC29910 -1-1/4" NPT | 1'' | 70 | S55 | S65 | 106 | 1-1/4"NPT |
HFSFC29910 -1-1/4"G | 1'' | 70 | S55 | S65 | 106 | 1-1/4"BSPP |
HFSFC29910 -1-5/16" UN | 1'' | 70 | S55 | S65 | 105 | 1-5/16"UN-12 |
HFSFC29910 -1-5/8" UN | 1'' | 70 | S55 | S65 | 106 | 1-5/8"UN-12 |
HFSFC299112 -1-1/2" NPT | 1-1/2'' | 92 | S65 | S85 | 133.5 | 1-1/2"NPT |
HFSFC299112 -1-1/2"G | 1-1/2'' | 92 | S65 | S85 | 133.5 | 1-1/2"BSPP |
HFSFC299112 -1-5/8" UN | 1-1/2'' | 92 | S65 | S85 | 133.5 | 1-5/8"UN-12 |
HFSFC299112 -1-7/8" UN | 1-1/2'' | 92 | S65 | S85 | 133.5 | 1-7/8"UN -12 |
Male
| Other Threads/Fitting Ends Are Available Upon Request | ||||||
| Art. No. | Body Size (inch) | N | M(mm) | Hp(mm) | Lp(mm) | T |
| HFSFP29938- 3/8"NPT | 3/8'' | M33x2 | 37.8 | 27 | 82.5 | 3/8"NPT |
| HFSFP29938-3/8"G | 3/8'' | M33x2 | 37.8 | 27 | 82.5 | 3/8"BSPP |
HFSFP29938- 1/2"NPT | 3/8'' | M33x2 | 37.8 | 27 | 86 | 1/2"NPT |
HFSFP29938-1/2"G | 3/8'' | M33x2 | 37.8 | 27 | 86 | 1/2"BSPP |
HFSFP29912- 1/2"NPT | 1/2'' | M40x3 | 45.8 | 36 | 97 | 1/2"NPT |
HFSFP29912-1/2"G | 1/2'' | M40x3 | 45.8 | 36 | 97 | 1/2"BSPP |
HFSFP29912 -1-1/16" UN | 1/2'' | M40x3 | 45.8 | 36 | 99 | 1-1/16"UN-12 |
HFSFP29958- 3/4"NPT | 5/8'' | M45x3 | 49.8 | 36 | 99 | 5/8"NPT |
HFSFP29958 -1-1/16" UN | 5/8'' | M45x3 | 49.8 | 36 | 99 | 1-1/16"UN-12 |
HFSFP29934- 1"NPT | 3/4'' | M50x3 | 54.8 | 46 | 114 | 1"NPT |
HFSFP29934-1"G | 3/4'' | M50x3 | 54.8 | 46 | 114 | 1"BSPP |
HFSFP29934 -1-1/16" UN | 3/4'' | M50x3 | 54.8 | 46 | 114 | 1-1/16"UN-12 |
HFSFP29934 -1-5/16" UN | 3/4'' | M50x3 | 54.8 | 46 | 114 | 1-5/16"UN-12 |
HFSFP29910 -1-1/4" NPT | 1'' | M58x3 | 64.5 | 55 | 123.5 | 1-1/4"NPT |
HFSFP29910 -1-1/4"G | 1'' | M58x3 | 64.5 | 55 | 123.5 | 1-1/4"BSPP |
HFSFP29910 -1-5/16" UN | 1'' | M58x3 | 64.5 | 55 | 123.5 | 1-5/16"UN-12 |
HFSFP29910 -1-5/8" UN | 1'' | M58x3 | 64.5 | 55 | 123.5 | 1-5/8"UN-12 |
HFSFP299112 -1-1/2" NPT | 1-1/2'' | M80x4 | 89.8 | 65 | 150 | 1-1/2"NPT |
HFSFP299112 -1-1/2"G | 1-1/2'' | M80x4 | 89.8 | 65 | 150 | 1-1/2"BSPP |
HFSFP299112 -1-5/8" UN | 1-1/2'' | M80x4 | 89.8 | 65 | 150 | 1-5/8"UN-12 |
HFSFP299112 -1-7/8" UN | 1-1/2'' | M80x4 | 89.8 | 65 | 150 | 1-7/8"UN-12 |
Accessories
| Dash Size | ISO Size | Art. No. Dust Cap For Coupler | Art. No.
Dust Cap For Plug | Material |
| 06 | 10 | 297-3/8-P-AL | 297-3/8-C-AL | Aluminum |
08 | 12.5 | 297-1/2-P-AL | 297-1/2-C-AL | Aluminum |
10 | 16 | 297-5/8-P-AL | 297-5/8-C-AL | Aluminum |
12 | 19 | 297-3/4-P-AL | 297-3/4-C-AL | Aluminum |
| 16 | 25 | 297-1-P-AL | 297-1-C-AL | Aluminum |
| 24 | 38 | 297-1-1/2-P-AL | 297-1-1/2-C-AL | Aluminum |
